Referencing an image within the vault via CSS content url

[andanteinblue]

What I’m trying to do

I’m trying add an image to be displayed as a part of a callout using the content url, using a construction like

.callout[data-callout=panel]::after {
  content: url("VaultImages/myimage.png");
}

But this does not work. If I change url to point to a weblink, then it works fine:

.callout[data-callout=panel]::after {
  content: url("https://upload.wikimedia.org/wikipedia/commons/e/e8/A_duck_%286125133746%29_%28cropped%29.jpg");
}

Things I have tried

This is the same issue that was raised in 2021 which received no resolution: CSS snippet to display image from vault? I have also tried the recommended solutions (using the file:/// , app:///, and even the obsidian://open?vault= Obsidian URL), but none of these seem to work.

[ariehen]

Obsidian’s CSS can’t refer to / use local files. You’ll have to base64 encode the image and add it to the .css file.

This is for themes, but it works the same in user snippets: Embed fonts and images in your theme - Developer Documentation

---

e.g. for a svg:

.callout[data-callout="panel"] {
    --callout-color: 208, 185, 240;
}
.callout[data-callout="panel"]::after {
}

[andanteinblue]

I see. Thank you for the explanation and solution!
